| Infrared Resolution |
384*288 |
| Thermal Sensitivity（NETD) |
＜0.03℃@30℃ |
| Temperature Measurement Range |
-20℃ to 120℃ (-4℉ to 248℉); |
| |
0℃ to 650℃(32℉ to 1202℉); |
| |
300℃ to 1550℃(572℉ to 2822℉); |
| |
smart switch between |
| User-definable Markers |
16 spot markers; 12 (rectangle or circle); 8 measurement lines |
| Focus Mode |
TurboFocus™ Speedy Intelligent Autofocus system for continuous, laser distance, graphic contrast,manual |
| Field of View（FOV）- Standard Lens |
25°×19° |
| Interchangable Lens Options |
Wide-angle:44°×34°(<0.1m), IFOV:2.0mrad |
| |
Telephoto:12°×9°(<0.25m), IFOV:0.55mrad |
| |
Ultra Telephoto:7°×5°(<1.0m), IFOV:0.32mrad |
| AI Programmable Key |
Yes, for quick start |
| Frame Rate |
30Hz |
| Lens Options |
Optional wide-angle lens,telephoto lens and ultra telephoto lens |
| Storage Memory |
128GB SD memory card |
| Accuracy |
± 2℃ or ± 2 %, whichever is greater（ambient temp between15℃~35℃) |
| On-screen Analysis |
Emissivity, Partially emissivity, Reflected temperaure, Ambient temperature, Humidity and Distance. |
| Sound Alarms |
Area alarm; High temperature alarm and low temperature alarm |
| Display |
Gorilla Glass Explosion-proof IPS LCD |
| |
Display pixels: 1280*720，Display size: 5inch (landscape) |
| Build-in Digital Camera (visible light) |
13-megapixel, industrial digital camera |
| Palettes |
15 standard palettes, 3 color isotherm, 15 inverted palettes |
| Image File Formats |
Standard JPEG with measurement data included |
| Video File Formats |
Full radiation thermal image video in IRS format; |
| |
standard MPEG4 non radiation video; |
| Remote Control Operations |
Remote display and control operation through Fotric AnalyzIR software |
| Battery Life |
Over 4 hours per battery |
| Battery Charging System |
Two-bay battery charger with LED display (12V, 3A) |
| Device Interface |
Support USB Type-C 3.0, Micro HDMI and SD card |
| Vibration |
EN 60068-2-6 |
| Drop |
Engineered to withstand 2 meters (6.5 feet) drop with standard lens |
| Enclosure Rating |
IP54 (protected against dust, limited ingress; protection against water spray from all directions), |
| |
GB/T 4208-2017/IEC60529:2013 |
| Shock |
EN 60068-2-27 |
| Eletromagnetic Compatibility |
EN 61326-1:2013 ( EN 61000-6-2) |
| |
EN 61326-1:2013 Class A ( EN 61000-6-3) |
| |
FCC 47 CFR Part15 Class A (emission) |
